Input/Output

• Simultaneous I/O up to 2 inputs/2 outputs
• 2 mic/instrument/line inputs with XMAX-L mic preamps
• 2 balanced 6,3 mm jack TRS main outputs
• 1 stereo headphone output
• MIDI In/Out
• 1 USB-C compatible 2.0 port
• USB-C to USB-C and USB-C to USB-A cables included for compatibility with most computers

Meters, Controls, and Features

• Mixer knob for low-latency direct input monitoring
• Front-panel level controls for main outputs
• +48V phantom power for condenser microphones (global)
• 4 ladder-style LED level meters (2 input, 2 main output)

Integrated Software

• Studio One Artist
• Studio Magic Plug-in Suite

Digital

• USB-C compatible port (USB 2.0)
• 24-bit resolution
• 44.1, 48, 88.2, 96, 176.4 and 192 kHz sampling rates

Physical

• Road-rugged construction with all-metal chassis and metal knobs
• USB bus-powered

• ADC Converter Dynamic Range: 108 dB
• DAC Converter Dynamic Range: 108 dB

Microphone Inputs

• Maximum Level: +10 dBu (±0.5 dBu, min gain)
• Gain Range: 50 dB
• Frequency Response: 20 Hz - 20 kHz (±0.3 dBu, unity gain, unwtd)
• Dynamic Range: 106 dB (A-wtd, min gain)
• THD + N: 0.004% (1 kHz, -1 dBFS, min gain)
• EIN: -126 dBu (A-weighted, 150 Ohm, max gain)
• Input Impedance: 1.4 kOhm
• Phantom Power: +48 VDC (10 mA total)

Instrument Inputs

• Maximum Level: +19 dBu (min gain)
• Gain Range: 50 dB
• Frequency Response: 20 Hz – 20 kHz (±0.1 dBu, unity gain, unwtd)
• Dynamic Range: 105 dB (A-wtd, unity gain)
• THD + N: 0.002% (1 kHz, min gain)
• Input Impedance: 750 kOhm

Main Outputs

• Type: 6,3 mm jack TRS, Female
• Maximum Level: +10 dBu (1 kHz, unity gain, balanced)
• Frequency Response: 20 Hz – 20 kHz (±0.3 dBu, unity gain, unwtd)
• Dynamic Range: 104 dB (unity gain, unwtd)
• THD + N: 0.001% ( 1 kHz, -1 dBFS, unity gain)

Headphone Outputs

• Maximum Power: 47 mW / channel @ 56 Ohm
• Frequency Response: 20 Hz – 20 kHz (±0.5 dBu, unity gain, unwtd)
• Dynamic Range: 83 dB (A-wtd, 56 Ohm load)
• THD + N: 0.01% (1 kHz, 0 dBFS, loaded)
• Impedance Working Range: 32 Ohm to 300 Ohm

• Dimensions: 44 x 180 x 144 mm
• Weight: 0,9 kg
• Colour: Black/Blue
