Produktkode: F1-MODEL-812 | ID: 224268
Compact full-range 1000 W PA system. Eight 2.25” speakers, vertically mounted on the FLEX array system provide multiple direction patterns to fit the necessary situation. Lower frequencies are handled by a 12” LF driver. The system has a built-in two channel mixer with one XLR / jack combo input and one RCA / 1/4" jack line input and a XLR output and has a subwoofer EQ switch. It is made of durable composite materials. Dimensions: 665 x 334 x 373 mm. Weight: 20 kg.
Technical Specifications System Performance |
||
System Type |
Self powered, two-way |
|
Frequency Response (–3 dB) |
52 Hz - 15.5 kHz |
|
Frequency Range (–10 dB) |
43 Hz - 20 kHz |
|
Nominal Dispersion |
100° H x 40° V (C-position) |
|
Maximum SPL @ 1 m |
132 dB SPL (peak) |
|
Crossover Frequency |
600 Hz Acoustic 4th order Butterworth |
|
Amplification |
||
System Power |
1000 W |
|
Distortion at Rated Power |
0.1 % Max (30 Hz - 15 kHz) |
|
System Limiter |
Dynamic limiter |
|
Power Indicator |
Blue LED: system on |
|
Transducers |
||
Driver Compliment |
8 x 2.25" mid-high drivers; 1 x 12" LF |
|
Channels |
||
Signal Indicators |
POWER/FAULT, LIMIT, FRONT LED, SIGNAL INPUT |
|
Input Connections |
Channel 1: XLR Balanced: Pin 1 (GND), Pin 2 (+), Pin 3 (-) |
|
Controls |
Volume level, Signal input select, Front LED function select, EQ select, Power on/off |
|
Additional Connections |
||
Line Output |
XLR balanced |
|
AC Mains |
IEC Connector |
|
Physical |
||
Enclosure |
High impact composite materials |
|
Grille |
Powder-coated perforated steel grille |
|
Dimensions |
26.1" H x 13.1" W x 14.6" D (664.66 x 334.3 x 372.5mm) |
|
Net Weight |
44.5 lbs (20.18 kg) |
|
Power Supply Voltages |
||
Universal |
AC power rating: 100-240 V 50 / 60 Hz +/- 20 % |
Parametre og specifikationer
Type
Bi-Amp
Ja
Multifunktionelt hylster
Nej
Montering af stang
Ja
DSP
EQ
Ja
Bluetooth
Nej
Frekvensområde
Bashøjttaler
Mellem højttaler
Tweeter
Skærm
Nej
Farve
Sort
Hylster
Polypropylen
Indgange
Udgange
Balanceret XLR M
MP3 / Line In
Ja
AUX IN
Ja
Mikrofon indgang
Ja
Effekt RMS (Watt)
500
Effekt RMS
500 W
Lydtryksniveau - SPL (dB)
Konfiguration af tilbud
Standard tilbud
Pakkens indhold
Adapterkabel
Effekt (Watt)
Strømforsyning
240 V
UK/EU Strømforsyning er inkluderet
Nej
Højde (cm)
66,5
Dybde (cm)
37,3
Vægt
20,18 kg
Lavet i
Kina
Anbefalet tilbehør
SÆT med tilbehør til nedsat pris. Du vil alligevel få brug for tilbehør før eller siden. Vælger du det nu, kan du spare masser af tid og penge og så behøver du ikke løse det senere. Derudover sikrer du dig at det angivne tilbehør i dette SÆT er egnet til det specifikke produkt.
Samlet bedømmelse baseret på 10 brugeranmeldelser:
